The BendPak HDS-14 is a rugged, heavy-duty four-post lift designed for larger vehicles and high-capacity requirements. Built to last with enhanced safety features, this lift is ideal for daily operations in service bays. Danbury Automotive Lifts offers this reliable, CE-certified lift that meets European Standard EN-1493 for quality and safety.
| Key Features | Details |
|---|---|
| Brand | BendPak (Offered by Danbury Automotive Lifts) |
| Lifting Capacity | 14,000 lbs (6,350 kg) |
| Max Capacity / Front Axle | 7,000 lbs (3,175 kg) |
| Max Capacity / Rear Axle | 7,000 lbs (3,175 kg) |
| Power Unit | 220 VAC, 60 Hz, 1 Phase |
| Noise Level | 45 dB |
| Locking Positions | 15 positions, spaced every 4” (102 mm) |
| Freestanding Design | Can be used standalone or anchored for added stability |
Lift Features
- High Lifting Capacity: Supports up to 14,000 lbs, perfect for larger and heavy-duty vehicles
- Enhanced Safety: Pneumatic push-button safety release, enclosed safety locks, and backup slack-cable safety latches
- Durable Build: Features heavy-duty 1/2″ aircraft cable, oversized cable rollers, and 1.75″ roller axles for durability
- Optional Add-Ons: Compatible with drive-thru ramps, drip trays, and 7,000-lb capacity rolling jacks (Model RJ7W)
- Quick Lifting: Reaches full rise in 60 seconds
- High-Quality Finish: Runways have a durable matte finish to withstand regular use
Specifications
| Description | Measurement |
|---|---|
| Min. Runway Height | 7.5″ (191 mm) |
| Max Rise | 70″ (1,778 mm) |
| Max Lifting Height | 77.5″ (1,969 mm) |
| Overall Width | 130″ (3,302 mm) |
| Outside Length | 213″ (5,410 mm) |
| Overall Length | 242″ (6,147 mm) |
| Height of Columns | 92″ (2,337 mm) |
| Drive-Thru Clearance | 98″ (2,489 mm) |
| Width Between Columns | 120″ (3,048 mm) |
| Runway Width | 20″ (508 mm) |
| Runway Length | 197.5″ (5,017 mm) |
| Width Between Runways | 34.5″ (876 mm) or 41.5″ (1,054 mm) |
| Runway Centerline | 57.5″ (1,461 mm) or 64.5″ (1,638 mm) |
| Outside Edge of Runways | 77.5″ (1,969 mm) or 84.5″ (2,146 mm) |
Minimum Wheelbase for Capacity
| Capacity | Wheelbase Requirement |
|---|---|
| Rated Capacity (100%) | 140″ (3,556 mm) |
| 75% Capacity | 120″ (3,048 mm) |
| 50% Capacity | 100″ (2,540 mm) |
| 25% Capacity | 80″ (2,032 mm) |
Locking & Safety
- Primary Locking Positions: 15 positions, spaced every 4” (102 mm)
- Backup Slack-Cable Safety Latches: Engage automatically for added safety
Shipping Information
| Shipping Weight | 2,606 lbs (1,182 kg) | | Shipping Dimensions | 209″ x 22″ x 29″ (5,309 mm x 558 mm x 737 mm) |
